型号 |
基本尺寸 |
轴径 |
额定负荷 |
螺栓规格 |
拧紧力矩 |
重量 |
安装相关尺寸 |
|||||
|
d |
D |
L |
H |
|||||||||
|
|
(mm) |
|
(KNM) |
(KN) |
|
(Nm) |
(kg) |
mm |
(mm) |
|||
|
SD125-51 |
125 |
185 |
39 |
52 |
95 100 105 |
11.5 13 14.5 |
242 260 276 |
M10×40 |
58 |
6 |
158 |
6 |
|
SD140-51 |
140 |
220 |
39 |
52 |
110 120 125 |
16 20 22 |
291 330 352 |
M10×40 |
58 |
8 |
175 |
6 |
|
SD155-51 |
155 |
234 |
39 |
52 |
130 135 140 |
25 28.8 32.5 |
385 427 464 |
M10×40 |
58 |
10 |
192 |
6 |
|
SD165-51 |
165 |
260 |
46 |
62 |
135 140 145 |
32 35.5 39 |
474 507 538 |
M12×50 |
100 |
14 |
210 |
8 |
|
SD175-51 |
175 |
275 |
46 |
62 |
145 150 155 |
39 43 47 |
538 573 606 |
M12×50 |
100 |
16 |
220 |
8 |
|
SD185-51 |
185 |
295 |
46 |
62 |
155 160 165 |
49 53 57 |
632 662 691 |
M12×50 |
100 |
20 |
225 |
8 |
|
SD195-51 |
195 |
315 |
56 |
72 |
165 170 175 |
66 71 76 |
800 835 869 |
M12×55 |
100 |
27 |
237 |
8 |
|
SD220-51 |
220 |
345 |
66 |
84 |
180 190 200 |
88 101 114 |
978 1063 1140 |
M16×65 |
240 |
35 |
265 |
9 |
|
SD240-51 |
240 |
370 |
66 |
84 |
200 210 215 |
120 134 141 |
1200 1276 1312 |
M16×65 |
240 |
44 |
290 |
9 |
|
SD260-51 |
260 |
395 |
72 |
92 |
220 230 235 |
144 159 167 |
1309 1383 1421 |
M16×70 |
240 |
48 |
310 |
9 |
|
SD280-51 |
280 |
425 |
84 |
104 |
230 240 250 |
170 190 210 |
1478 1583 1680 |
M16×75 |
240 |
60 |
333 |
10 |
|
SD300-51 |
300 |
460 |
84 |
104 |
250 260 270 |
213 234 255 |
1704 1800 1889 |
M16×75 |
240 |
75 |
358 |
10 |
|
SD320-51 |
320 |
495 |
84 |
106 |
270 280 290 |
264 285 301 |
1955 2036 2076 |
M16×80 |
240 |
84 |
378 |
11 |
|
SD340-51 |
340 |
535 |
84 |
106 |
290 300 305 |
318 345 359 |
2193 2300 2354 |
M16×80 |
240 |
100 |
402 |
11 |
|
SD360-51 |
360 |
555 |
100 |
122 |
300 310 320 |
382 410 438 |
2547 2645 2738 |
M20×90 |
470 |
125 |
423 |
11 |
|
SD390-51 |
390 |
595 |
112 |
136 |
330 340 350 |
510 543 576 |
3091 3194 3291 |
M20×100 |
470 |
156 |
452 |
12 |
|
SD420-51 |
420 |
630 |
120 |
144 |
350 360 370 |
590 630 670 |
3371 3500 3620 |
M20×100 |
470 |
185 |
485 |
12 |
|
SD460-51 |
460 |
685 |
132 |
158 |
390 400 410 |
770 860 950 |
3949 4300 4634 |
M20×110 |
470 |
235 |
527 |
13 |
|
SD500-51 |
500 |
750 |
152 |
178 |
420 430 440 |
1025 1125 2225 |
4881 5233 5568 |
M20×120 |
470 |
320 |
572 |
13 |
