产生氨基醇钢筋阻锈剂厂家YJ-R5051复合氨基醇钢筋阻锈剂

型号：

cm型混凝土防腐剂抗硫酸盐类侵蚀防腐剂

规格：

抗硫酸盐类侵蚀防腐剂

                                                      Composite amino alcohols of rebar inhibitor

                                                                 复合氨基醇钢筋阻锈剂
Advisory 13716267347

YJ-R505是一种内掺型（DCI）复合氨基醇类有机阻锈剂，由多种不同类型的醇胺类有机物与具有特定阻锈作用的无机组分复合而成，不含亚硝酸盐。混凝土中加入YJ-R505后，阻锈剂中的不同组分能够在钢筋表面形成吸附膜、沉淀膜以及氧化膜，起到阻断有害物质与钢筋表面的接触，阻止或延缓锈蚀发生的时间；同时YJ-R505具有一定的减水效果，能够有效改善混凝土拌合物的性能以及提高混凝土抗渗性能，降低溶解氧的扩散速率以及氯离子的扩散系数。二者综合作用，最终达到提高混凝土结构的耐久性，延长混凝土结构使用寿命的目的。

YJ-R505 is a mixed type (DCI) composite amino alcohols of organic inhibitor, by alcohol amine to many different types of inorganic group has certain rust of compound and into, does not contain nitrite. Join YJ-R505 to concrete, different groups of inhibitors of membrane, membrane can adsorb and oxide film formed on the steel surface, to blockade the harmful substances and steel surface contact, prevent or delay the corrosion occurred; at the same time, YJ-R505 has the effect of reducing the water, can effectively improve the performance of concrete mixture and impermeability of concrete increases, reduce the diffusion rate of dissolved oxygen and diffusion coefficient of chloride ions. The comprehensive function of the two, and finally improve the durability of the concrete structure, extend the service life of concrete structure to.

适用范围：

Scope of application:

1、水工建筑（大坝、桥梁隧道等）、海工建筑（护堤、码头等）、地下设施（地铁、地下停车场）、建筑物基础以及混凝土结构的加固与修补。

1, hydraulic structures (dam, bridge and tunnel etc.), marine structures (berm, dock etc.), underground facilities (subway, underground parking lot), building foundation and concrete structure strengthening and repairing.

2、各类工业污水池、水塔、贮罐、粮仓、油罐、山洞内存贮库等。

2, all kinds of industrial sewage pool, water tower, storage tank, tank, granary, cave of memory storage.

3、使用海砂建筑、使用化冰盐的结构。

3, the use of sea sand building, use of deicing salt structure.

4、公路、铁路等预应力结构以及其他重要的建筑。

4, highway, Railway Prestressed Structure and other important buildings.

阻锈性能

Rust inhibiting properties

项目 标准指标 YJ-R505检测指标

Project standard YJ-R505 detection index

盐水浸渍试验 电位 0～-250 mv 电位 0～-200 mv

Salt water immersion test potential of 0 ~ -250 MV potential of 0 ~ -200 MV

混凝土浸烘试验（相对于不掺阻锈剂） 锈蚀面积减少 95%以上 锈蚀面积减少 98%以上

Leaching and drying experiment of concrete (relative to the non doped rust corrosion area) is less than 95% corrosion area is less than 98%

混凝土性能

The performance of concrete

项目 标准指标 掺 YJ-R505钢筋阻锈剂混凝土性能

Project standard YJ-R505 doped reinforced concrete corrosion inhibitor performance

抗压强度比，% >90 100～120

Compressive strength ratio,% >90 100 ~ 120

凝结时间差，min -120～+120 -60～+120

Condensation time difference, min -120 to +120 -60 to +120

抗渗性 不降低 不降低

Impermeability not reduced without decreasing the

推荐掺量

Recommended dosage

环境类型 单方混凝土掺量（kg/m3）

Environment type unilateral concrete admixture (kg/m3)

轻度腐蚀环境 一般建筑、地下工程、预应力孔道、预应力结构 8～10

Mildly corrosive environment building, underground engineering, prestress, prestressed structure is 8 ~ 10

重度腐蚀环境 海洋海港工程的水位变动区和浪溅区结构、桥梁、氯离子含量大于 5000 mg/L的盐碱地地区、污水处 理池结构 10～16

Severe corrosive environment of Marine Harbour Engineering fluctuating water level zone and splash zone structure, bridge, chloride ion content of more than 5000 mg/L of saline alkali land area, the sewage treatment pool structure of 10 ~ 16

施工注意事项

The matters needing attention in the construction

1、YJ-R505略有减水作用，可在保持原流动度的情况下适当减水。

1, YJ-R505 slightly decrease water effect, can maintain the original flow conditions appropriate to reduce water.

2、本品适应于通用水泥、特种水泥和粉煤灰、矿渣粉及硅灰等矿物掺合料，与常用减水剂有较好的相容性。

2, this product is suitable for general cement, special cement and fly ash, slag and silica fume admixture, and common water reducing agent has good compatibility.

3、加入本品的混凝土工程，必须事先做配合比试验。

3, to join the concrete project of this product, must first do mix ratio test.

4、在高质量混凝土中才能更有效地发挥作用，必须遵守相关规范和设计规定，确保混凝土质量与密实性。

4, the high quality of concrete can be more effectively play a role, must comply with the relevant standards and design regulations, to ensure the concrete quality and compactness.

5、本品为液体，50 kg或 200 kg桶装，需密封、避光、阴凉处保存，储存期六个月。

5, the product is liquid, 50 kg or 200 kg barreled, sealing, avoid light, preserved in cool and dry place, storage period of six months.

YJ-R505复合氨基醇类混凝土钢筋阻锈剂阻锈性能试验

Composite amino alcohols concrete reinforcement rust inhibitor rust performance test of YJ-R505

YJ-R505复合氨基醇类阻锈性能试验研究包括盐水浸渍试验与混凝土浸烘试验，具体试验方法参照YB/T9231《钢筋阻锈剂使用技术规程》进行。

Experimental study on Corrosion Properties of YJ-R505 composite amino alcohols resistance including drying immersion test salt solution immersion test and concrete, specific test method according to YB/T9231 "rebar inhibitor use of technical regulations".

备注：

Remarks.

1、盐水浸渍实验：添加YJ-R505的氯化钠溶液，钢筋光洁如新，未出现任何锈斑，阻锈效果显著。

1, salt solution immersion test: Sodium Chloride Solution add YJ-R505, reinforced bright, no rust, rust effect.

2、海工耐久混凝土原材料要求：

2, marine durable concrete raw materials:

1、Po. 42.5 硅酸盐水泥

1, Po. 42.5 Portland cement

2、粉煤灰、矿渣、微硅粉等掺合料

2, fly ash, slag, silica fume and other admixtures

3、最大粒径不超过25 mm的非活性集料

3, the maximum size of not more than 25 mm of non active aggregate

4、不得使用海砂和人工砂

4, do not use sand and artificial sand

5、减水率至少达25%的高效外加剂，混凝土中应加入适量复合氨基醇类混凝土钢筋阻锈剂原材料中限制氯离子含量。

5, high rate of water reducing admixture of at least 25%, should limit the content of chlorine ion by adding proper amount of composite amino alcohols concrete reinforcement rust inhibitor in raw material of concrete.

3、使用说明

3, instructions for use

1、YJ-R505掺入混凝土中，阻止或延缓钢筋锈蚀，在国际分类中，属于“掺入型”（DCI）。

In 1, YJ-R505 in concrete mixing, prevent or delay the corrosion of reinforcement, in international classification, belongs to the "mixed" type (DCI).

2、将YJ-R505与计量水、水泥、集料同时加入混凝土搅拌机中，适当延长搅拌时间，确保搅拌均匀。

2, the YJ-R505 and the measurement of water, cement, aggregate simultaneously to join the concrete mixer, prolong mixing time, ensure uniform mixing.

3、YJ-R505与其它外加剂复合使用时，应先做混凝土试配，以确定其适应性；配制混凝土所用原料应符合《建筑用卵石、碎石》GB/T14685和《建筑用砂》GB/T14684。

3, YJ-R505 and other admixture compound use, should do first concrete test, to determine their adaptability; the raw materials shall be in accordance with the "building of pebble, gravel and sand for building" GB/T14685 "" GB/T14684 concrete.

4、YJ-R505粉剂如有轻微吸潮结块可溶于水中使用，液剂产品表面可能会有泡沫，不影响使用。在运输、储存过程中应避免雨淋、受潮，阴凉通风保存，远离易燃易爆物，严禁明火。

4, YJ-R505 powder as a slight hygroscopic agglomerate soluble in water use, surface liquid products may have a bubble, does not affect the use. In the process of transportation, storage should avoid drench, damp, cool ventilated preservation, away from flammable and explosive materials, is strictly prohibited fire.

5、操作人员宜佩带口罩、橡皮手套等必要防护措施。废液、废粉不得随意倾倒

5, the operator should wear masks, rubber gloves and other necessary protective measures. Waste water, waste powder shall not arbitrarily dumping
