- 型号:
- 聚异三聚氰酸脂夹心芯保温板
PIR 聚异氰脲酸酯隔热板材
技术参数 Technical Date
项 目 Item |
单 位 Unit |
技术参数
Technical Date |
|
密 度 Density | K/m3 | ≥35 | |
导热系数 ThermalConductivity |
新鲜样品 Fresh Sample |
W/(m·K) | ≤0.0196(+23℃) |
老化样品 Aged Sample |
≤0.0162(-160℃) | ||
≤0.0183(-120℃) | |||
≤0.0205(-100℃) | |||
≤0.0218(-50℃) | |||
≤0.0218(+20℃) | |||
抗压强度(压缩10%) Compressive Strength At 10% Relative Deformation |
常 温 Ambient Temp. |
Kpa |
各方向≥200(23℃)
All Direction≥200 (23℃) |
液氮浸8小时 8h in LiquidN2 |
各方向≥280(-160℃)
All Direction≥280 (-160℃) |
||
燃烧性 Combustibility |
最大火焰蔓率
Max. flame spread |
|
<25 |
阻燃等级
Rating |
|
B1级 | |
氧 指 数(OI) Oxygen Index |
|
≥30 | |
吸 水 率
Water Absorption |
% | ≤5% (体积By VOL) | |
水蒸气透湿系数(50%RH) Water Vapor Permeability |
g/(m2·h) | ≤0.8 | |
线性热膨胀系数 Lineal Thermal Expansion Coefficient |
m/(m·K) | ≤70×10-6 | |
氯离子含量
Chlorides Content |
ppm | ≤60 | |
推荐使用温度
The proposedService temp. |
℃ | -196~+150 |
