* 采用玻璃长纤维以非织物方式制成,透风量大,
阻力小,对漆雾捕尘效率佳;
* 高强度的玻璃纤维递增结构; 迎风面为绿色,
出风面为白色;
* 低压缩性能保持漆雾毡外型不变,使其过滤纤维
完全有利于储存油雾灰尘;
* 耐燃性,可耐温170℃;
* 压缩真空包装在运输上可节约运费及储存空间，放松后仍可恢复原来状态；
用途:
喷漆房及喷漆设备系统中漆雾的诱捕，厨房、化工系统油烟的吸附，最终使排放气体达到 环保要求。
Floor filter
Specialty:
*processed by long fiberglass fiber in non-woven way, large ventilation quantity and low resistance can keep better filter effect.
*The high performance fiber with gradual increasing density toward pure air, Windward side is green, leeward side is white.
*Low compressibility keeps its shape and benefit for capture paint, mist, soot, etc.
* Temperature resistance: 170℃.
*you can compress in transportation, when release it can recover immediately.
Application:
Applied in many industries, such as painting industry, air conditioning, electronic, pharmaceutical factory, food sanitation etc.
技术参数: Specification
|
型 号Type |
自由状态厚度Thickness (mm) |
不同风速(m/s)时的阻力Pa |
不同粒径下的平均效率（%） |
容尘量 Dust Holding Capacity (g/m2) |
耐温度Temperature Resistance |
||||
|
1.3 |
2.6 |
3.9 |
≥2μm |
≥5μm |
≥10μm |
||||
|
PA-50 |
50 |
15 |
30 |
45 |
35 |
70 |
80 |
1850 |
170℃ |
|
PA-60 |
60 |
20 |
35 |
50 |
40 |
75 |
85 |
2100 |
170℃ |
|
PA-100 |
100 |
25 |
40 |
55 |
60 |
80 |
90 |
3200 |
170℃ |
|
标准 尺寸 |
0.8/1/2x20m |
||||||||
注:可根据需要定制不同规格. Note: Special Size Available Upon Request.
