简介
生物可溶性纤维是一种人造的，玻璃态硅酸盐高温隔热纤维。生物可溶性纤维按照欧盟法规67/548 NOTA Q标准，不属于任何致癌物分类。作为耐火陶瓷纤维（RCF）的替代品，生物可溶性纤维系列产品替代传统的隔热方案，为商业、工业和交通运输业提供灵活的隔热解决方案。
生物可溶性纱以高强生物可溶性纤维为原料，经纺纱、络筒而成。根据不同的使用温度，不同使用条件，加入玻璃纤维或者耐热合金丝等增强材料，使其连续使用温度达1050°C。短时间使用温度也可达1260°C。具有良好的抗酸碱腐蚀性与抗铝、锌等熔融金属侵蚀能力。
参数表
|
项目 |
数值 |
|
颜色 |
白 |
|
最高使用温度 |
1260°C |
|
纤维直径 |
3~5μm |
|
热收缩率（1232°C，24h） |
3.5% |
|
热传导率（538°C，8pcf） |
0.130w/mk |
|
渣球含量 |
< 8.5% |
|
击穿电压 |
5kv/mm |
|
体电阻 |
5x10 10Ω |
|
含水率 |
< 2% |
|
有机纤维含量 |
< 20% |
应用范围
l 各种纺织品；
包装：每轴装一个塑胶袋；
Introduction
Bio soluble AES fiber is a high-temperature insulating wool composed of man-made vitreous silicate fibers.Bio soluble AES fiber is exonerated from the carcinogen classification in the European union under the term of NOTA Q of European Directive 67/548/EEC. Bio soluble AES fiber has been developed to show improved high temperature characteristics required to act as an alternative to RCF. The Bio soluble AES fiber fiber textiles offer a versatile alternative to traditional insulation solutions for commercial, industrial, and transportation applications.
Bio soluble AES fiber yarn is produced by high quality Bio soluble AES fiber.It can be used for high temperature applications up to1050°C. The cloth is reinforced with fiberglass filament, and optional stainless steel wire (Inconel/alloy steel wire). Or even short working temperature could be reached to1260°C. It has good resistance to acid corrosion, resistant aluminum, zinc and other molten metal erosion.
Parameter table
|
Type |
Data |
|
Color |
Green |
|
Max working temp |
1260°C |
|
Fiber diameter |
3~5μm |
|
Heat shrinkage（1232°C，24h） |
3.5% |
|
Thermal conductivity（538°C，8pcf） |
0.130w/mk |
|
Shot |
< 8.5% |
|
Breakdown voltage |
5kv/mm |
|
Resistance |
5x10 10Ω |
|
Moisture content |
< 2% |
|
Organic fiber content |
< 20% |
Continuous working temp:1050°C(1900°F);
Maximum working temp:1260°C(2300°F);
Application
l All kinds of textiles;
