规格 |
口径 |
执行器型号 |
L1 |
H1 |
L2 |
H2 |
H |
Dф |
|
605515 |
DN15 |
931001 |
88.0 |
58.0 |
112.0 |
73.0 |
165.0 |
45.0 |
|
605520 |
DN20 |
931001 |
88.0 |
58.0 |
132.0 |
78.0 |
175.0 |
55.0 |
|
605525 |
DN25 |
931002 |
158.0 |
103.0 |
144.0 |
105.0 |
252.0 |
66.0 |
|
605532 |
DN32 |
931005 |
158.0 |
103.0 |
165.0 |
115.0 |
270.0 |
82.0 |
|
605540 |
DN40 |
931005 |
158.0 |
103.0 |
171.0 |
122.0 |
286.0 |
98.0 |
|
605550 |
DN50 |
931005 |
158.0 |
103.0 |
200.0 |
135.0 |
310.0 |
120.0 |
|
说明： 若阀座材料为PP，订货号尾数加P；若阀座材料为PTFE，订货号尾数加T。 |
