概述
90年代初随着无线通信行业的发展，热交换器广泛应用于通信行业户外机柜散热、电信机房、大型计算中心散热等封闭空间散热领域。
由于热交换器IP等级高、运行可靠、维护费用低、寿命长等特点，越来越多的高端电子、电源柜也开始采用热交换器。
可根据客户的换热量、控制方式、电源方式、尺寸等要求定制产品。
> 热交换器分为内外两个工作循环，而且相互隔绝，达到防水、防尘的目的。两个循环在热交换器内部进行热量交换。
> 外循环：外界冷空气通过#1进风口进入热交换器，通过换热芯，吸收内循环热空气所传过来的热量，温度升高，从#2排风口排出。
> 内循环：机柜内部电子元器件产生的热量使内部温度升高，高温气体通过#3进风口进入热交换器，将热量通过换热芯传给外循环的冷空气，变成较低温度的气体，从#4号排风口重新进入机柜冷却电子元器件。
|
Items |
Unit |
De |
Models |
|||||||||
|
HHh-040 |
HHh-060 |
HHh-080 |
HHh-100 |
|||||||||
|
Cooling Capacity制冷量 |
W/K |
|
40 |
60 |
80 |
100 |
||||||
|
Heater加热量 |
W |
Optional |
300,500 |
500,800,1000 |
||||||||
|
Air Flow风量 |
M3/h |
Internal air flow内风量 |
240 |
360 |
490 |
620 |
||||||
|
Fan type分级类型 |
|
|
Backward Centrifugal Fan后弯离心风机 |
|||||||||
|
Temp.温度范围 |
°C |
Operation range操作范围 |
-40-60°C 0-90%RH |
|||||||||
|
Noise噪音 |
dB(A) |
3m,away ETS300-753 |
50 |
52 |
55 |
55 |
||||||
|
Dimension尺寸 |
mm |
W*H*D |
320*800*150 |
425*1122*150 |
||||||||
|
Weight重量 |
Kg |
Net weight净重 |
12 |
13.5 |
21 |
22 |
||||||
|
Power Consumption功耗 |
W |
DC:48V |
62 |
87 |
122 |
131 |
||||||
|
AC: 230V/110V |
78 |
96 |
143 |
154 |
||||||||
|
Power Supply电源 |
V |
Rated |
24VDC,48VDC,230VAC/110VAC,50/60Hz |
|||||||||
|
IP grade IP等级 |
|
IEC6052 |
>=Ip55 |
|||||||||
|
Items |
Unit |
De |
Models |
|||||||||
|
HHh-120 |
HHh-150 |
HHh-200 |
HHh-250 |
|||||||||
|
Cooling Capacity |
W/K |
|
120 |
150 |
200 |
250 |
||||||
|
Heater |
W |
Optional |
500,800,1000 |
800,1000,2000 |
||||||||
|
Air Flow |
M3/h |
Internal air flow |
720 |
920 |
1200 |
1500 |
||||||
|
Fan type |
|
Operation range |
Backward Centrifugal Fan |
|||||||||
|
Temp. |
°C |
Operation range |
-40-60°C 0-90%RH |
|||||||||
|
Noise |
dB(A) |
3m,away ETS300-753 |
57 |
57 |
58 |
58 |
||||||
|
Dimension |
mm |
W*H*D |
450*1172*200 |
550*1572*220 |
||||||||
|
Weight |
Kg |
Net weight |
24 |
25 |
37 |
39 |
||||||
|
Power Consumption |
W |
DC:48V |
148 |
157 |
200 |
210 |
||||||
|
AC: 230V/110V |
170 |
185 |
227 |
246 |
||||||||
|
Power Supply |
V |
Rated |
24VDC,48VDC,230VAC/110VAC,50/60Hz |
|||||||||
|
IP grade |
|
IEC6052 |
>=Ip55 |
|||||||||
|
Items |
Unit |
De |
Models |
|||||||||
|
HHh-300 |
HHh-350 |
|||||||||||
|
Cooling Capacity |
W/K |
|
300 |
350 |
||||||||
|
Heater |
W |
Optional |
1500,2000 |
|||||||||
|
Air Flow |
M3/h |
Internal air flow |
1860 |
2170 |
||||||||
|
Fan type |
|
Operation range |
Backward Centrifugal Fan |
|||||||||
|
Temp. |
°C |
Operation range |
-40-60°C 0-90%RH |
|||||||||
|
Noise |
dB(A) |
3m,away ETS300-753 |
60 |
60 |
||||||||
|
Dimension |
mm |
W*H*D |
650*1780*240 |
650*1780*240 |
||||||||
|
Weight |
Kg |
Net weight |
49 |
51 |
||||||||
|
Power Consumption |
W |
DC:48V |
300 |
330 |
||||||||
|
AC: 230V/110V |
320 |
350 |
||||||||||
|
Power Supply |
V |
Rated |
24VDC,48VDC,230VAC/110VAC,50/60Hz |
|||||||||
|
IP grade |
|
IEC6052 |
>=Ip55 |
|||||||||
