全自动纸杯（纸碗）外套粘合机
Wt-30 Paper Cup/Bowl Sleeve Machine Description:
Model WT-30 Paper Cup/Bowl Sleeve Forming & Wrapping Machine is an automatic equipment to make a second wall sleeve over the inner-cup/bowl(cup/bowl by paper cup/bowl machine).wear a sleeve around the paper cup/bowl.
It is the matching equipment of (ZB0A12) Paper Cup Machine &( ZW-A35),Paper bowl machine,which has the function as photo cell detectioin,failure alarm,counting etc.
It makes double wall paper cup/bowl after running a whole procedure of automatic paper (fan-sleeve)feeding,sleeve cone-body sealing(by ultrasonic wave),water-glue sprying (spray glue inside the cone-sleeve),cup./bowl feeding (absorb cup into the cone-sleeve),inserting and bonding sleeve to the cup collecting with the function of photo electric detection,fault alarm,and count.
It is an ideal equipment of making two/double walls paper cups/bowls such as direct-sleeves cups, ollow-sleeve cups etc. he sleeve-wrapped paper cups are popular  for hot drinks tea coffee, etc
全自动纸杯（纸碗）外套粘合机是紧跟市场需要而开发设计的，是ZB-A12型纸杯机和ZW-A36型纸碗机的配套设备。具有自动送纸（印好的外套扇形片）、超声波缝合（形成外套层）、喷胶（在外套内壁）、下碗/杯（已经做好的内层用纸杯，纸碗）、外套与纸碗自动粘合以及光电检测、故障报警、计数等功能。工艺先进，设计合理，设备操作，维护方便。
全自动纸杯（碗）外套粘合机的工作原理是在做好的纸杯、纸碗外再套上一层（隔热），用于生产双层纸杯（咖啡果冻纸杯=香飘飘奶茶两层纸杯等）或两层纸碗（如：康师傅方便面碗，统一方便面晚等）。
主要技术参数 Main Tehinical Parameters
纸杯规格：6-16盎司纸杯:20-50盎司纸碗（模具可调换），
Paper Cup Size:6-16 oz cup/20-50oz bowl(mold exchange able)
纸质原料：PE淋膜纸，以及其他类似淋膜纸（170-350）克；
Raw Material:PE paper,Varnishing Printed Paper,or other film coated paper(can be sealed by ultrasonic);Suitable paper weight:170-350gsm(recommend 250-300gsm)
生产速度：40-50只/分钟
Rated Productivity:40-50 pcs/min
电源要求：220V50 HZ 和380 50HZ都可使用。
Power Source:220/50HZ,380/50HZor other required
总功率：4KW
Total Power:4KW
机器重量：1000KG
Total Weight:1000kg
外形尺寸：长*宽*高 2200*1100*1600mm
Pacakge Size(L*W*H)2200*1100*1600mm
