gpz桥梁盆式橡胶支座报价

盆式橡胶支座的结构原理是安置于密封钢盆中的橡胶块，在三向受力的情况下，而产生的反力，承受桥梁的垂直荷载，同时，利用橡胶的弹性，满足梁端的转动，通过焊接在上座板上的不锈钢板与聚四氟乙烯的自由滑移，完成桥梁上部构造的水平位移。本系列产品具有结构合理，承载能力大，变形小，水平位移量大，转动灵活，并有良好的缓冲性能，是建筑连续式桥梁的最佳支座，
The structure principle of rubber support is arranged on the sealing rubber piece of steel in the basin, in three to force under the condition of anti force, vertical load, under the bridge at the same time, the use of rubber elasticity, meet the rotation of the beam end, the stainless steel plate and polytetrafluoroethylene welded on the upper seat board. The free slip, the horizontal displacement of the upper structure of the bridge is completed. This series of products has such advantages as reasonable structure, large load capacity, small deformation, large horizontal displacement, flexible rotation and good cushioning performance. It is the best support for building continuous bridges.
盆式橡胶支座特点及分类:
Basin type rubber bearing features and classification:
盆式橡胶支座且具有重量轻，结构紧凑，构造简单，建筑高度低，加工制造方便，节省钢材，降低造价等优点，是适宜于大垮桥梁使用的较理想的支座。常用的有GPZ、GPZ（Ⅱ）、GPZ(KZ)三大类。 GPZ(II)系列支座目前承载力为31个级别，承载力0.8MN-60MN，能满足大型桥梁建造的需要。
The basin rubber bearing has the advantages of light weight, compact structure, simple structure, low building height, convenient processing and manufacturing, saving steel and reducing cost. It is an ideal support suitable for the use of big break bridges. There are three commonly used categories: GPZ, GPZ (II) and GPZ (KZ). The bearing capacity of GPZ (II) series is 31 grades at present and the bearing capacity is 0.8MN-60MN, which can meet the needs of large bridge construction.
GPZ(II)标准系列中，固定支座在各方向和单向活动支座非滑移方向的水平承载力均不小于支座坚向承载力的10%。抗震型支座水平承载力不小于支座坚向承载力的20%。 支座转动角度不小于0.02rad.  加5201硅脂润滑后，常温型活动支座设计摩阻系数最小取0.03.;加5201硅脂润滑后，耐寒型活动支座设计摩阻系数最小取0.06。
In the GPZ (II) standard series, the horizontal bearing capacity of the fixed bearing in the direction of non slip in all directions and unidirectional bearings is not less than 10% of the bearing capacity of the bearing. The horizontal bearing capacity of the aseismic support is not less than 20% of the support bearing capacity. Bearing rotation angle is not less than 0.02rad. 5201 grease lubrication, normal temperature type movable bearing design minimum friction coefficient 0.03.; add 5201 grease lubrication, cold type movable bearing design friction coefficient minimum 0.06.

盆式橡胶支座分类
Classification of basin rubber bearing
盆式橡胶支座根据应用范围可以分为三大类：
The basin rubber bearing can be divided into three categories according to the scope of application:
公路桥梁盆式橡胶支座、铁路桥梁盆式橡胶支座及盆式橡胶支座的衍生品。常用的公路盆式橡胶支座型号有：GPZ盆式橡胶橡胶支座和GPZ（Ⅱ）盆式橡胶橡胶支座(依据GT391-1999) ,GPZ(KZ)盆式橡胶支座等几个系列。常用的铁路盆式橡胶支座有TPZ-I铁路盆式橡胶支座，TPZ标铁路盆式橡胶支座，专桥8156铁路桥梁支座。 盆式橡胶支座的衍生品种类很多，比如 QPZ盆式橡胶橡胶支座、KPZ系列盆式橡胶支座、弹性减震球型钢支座、自调高盆式橡胶支座等。每一类根据位移形式可分为固定(GD)、单向活动(DX)和双向活动(SX)三种。
The derivatives of the rubber bearing of the road and bridge, the rubber bearing of the railway bridge and the rubber bearing of the basin type. The usual types of highway basin rubber bearings are: GPZ basin rubber rubber bearings and GPZ (II) basin rubber rubber bearings (GT391-1999), GPZ (KZ) basin rubber bearings and so on. The common rubber bearing of railway basin type has TPZ-I railway basin rubber bearing, TPZ standard railway basin type rubber bearing, and 8156 railway bridge support for special bridge. There are many kinds of derivatives for basin rubber bearings, such as QPZ basin rubber rubber bearings, KPZ series basin rubber bearings, elastic shock absorbing ball steel bearings, self adjusting high basin rubber bearings and so on. Each type can be divided into three types according to the form of displacement (GD), one way activity (DX) and two way activity (SX).

安装盆式橡胶支座
Installation of basin rubber bearing
1、把锚柱安装在盆式橡胶支座底板四角。
1. The anchor column is installed at four corners of the bottom plate of the basin rubber bearing.
2、浇注盆式橡胶支座支墩，留出顶端一段高度，留出高度要比支座的锚柱大些；
2, pouring basin type rubber bearing buttress, leaving the top part of the height, leaving the height more than the support of the anchor column.
3、把盆式橡胶支座吊到垫石上方，校正平面位置和高度；
3, the basin type rubber bearing is suspended above the cushion, and the position and height of the plane are corrected.
4、浇注垫石混凝土；
4, pouring padding stone concrete;
5、安装盆式橡胶支座上部的4个锚柱；
5, 4 anchor columns on the upper part of the basin rubber bearing;
6、安装现浇梁模板，绑扎现浇梁钢筋；
6. Install cast-in-place beam formwork and bind cast-in-place beam.
7、浇注梁体混凝土；
7, cast beam concrete;
8、拆除盆式橡胶支座两侧的临时连接
8. Dismantling the temporary connections on both sides of the basin rubber bearing
